Experience next-generation home heating with the AUX R290 Monoblock Heat Pump, combining ultra-quiet performance, eco-friendly design, and exceptional energy efficiency to deliver powerful, low-cost heating while keeping your comfort and sustainability in perfect balance.
Efficient, Silent and Eco-Friendly Home Heating
The AUX R290 Monoblock Heat Pump is a next-generation heating system designed to provide efficient, quiet, and sustainable home comfort all year round. Using the eco-friendly R290 refrigerant, this unit offers outstanding energy performance while keeping operating noise levels impressively low. Built with advanced technology and durable materials, the R290 Monoblock delivers reliable performance for homeowners who value both comfort and sustainability.
Class-Leading Efficiency
- A+++ Rating: Rated for maximum efficiency at both 35 °C and 55 °C flow temperatures.
- High SCOP: MCS listed with the highest SCOP scores in its class.
- Built-in Backup: Integrated 3kW heater ensures reliability during extreme peaks.
Optimized Performance
- Full Output: Maintains 100% capacity even at -7 °C outdoor temperatures.
- Fit & Notify: 4, 6, 8, and 10kW units qualify for easy DNO notification.
- Compact Safety: Minimal 300mm safety clearance required for flexible placement.
Peace of Mind
- Ultra Quiet: Whisper-soft operation at just 35 dB at a 3 m distance.
- 10 Year Warranty: Industry-leading protection for long-term investment.
- Eco-Friendly: Uses R290 refrigerant for ultra-low global warming impact.
| Capacity | Model | Backup Heater | Power | SCOP (35°C) | SCOP (55°C) | Photo | Dimensions |
|---|---|---|---|---|---|---|---|
| 4kW | ACHP-H04/4R2HA-M | 3kW | 220V-240V1N~50Hz | A+++ | A+++ |
|
|
| 6kW | ACHP-H06/4R2HA-M | 3kW | 220V-240V1N~50Hz | A+++ | A+++ | ||
| 8kW | ACHP-H08/4R2HA-M | 3kW | 220V-240V1N~50Hz | A+++ | A+++ |
|
|
| 8kW (NE) | ACHP-H08/4R2HA-M(NE) | No Heater | 220V-240V1N~50Hz | A+++ | A+++ | ||
| 10kW | ACHP-H10/4R2HA-M | 3kW | 220V-240V1N~50Hz | A+++ | A+++ | ||
| 10kW (NE) | ACHP-H10/4R2HA-M(NE) | No Heater | 220V-240V1N~50Hz | A+++ | A+++ | ||
| 12kW | ACHP-H12/4R2HA-M | 3kW | 220V-240V1N~50Hz | A+++ | A+++ | ||
| 14kW | ACHP-H14/4R2HA-M | 3kW | 220V-240V1N~50Hz | A+++ | A+++ | ||
| 16kW | ACHP-H16/4R2HA-M | 3kW | 220V-240V1N~50Hz | A+++ | A+++ |
R290 Series: Seasonal Heating Performance & Efficiency Matrix
| Temperature | Measurement | H04/4R2HA | H06/4R2HA | H08/4R2HA | H10/4R2HA | H12/4R2HA | H14/4R2HA | H16/4R2HA |
|---|---|---|---|---|---|---|---|---|
| Heating A7W35 | Capacity (W) | 4568 | 6290 | 8400 | 10000 | 14930 | 16170 | 17820 |
| Rated input (W) | 880 | 1270 | 1680 | 2080 | 3330 | 3740 | 4250 | |
| COP | 5.20 | 4.95 | 5.00 | 4.80 | 4.49 | 4.32 | 4.19 | |
| Heating A7W45 | Capacity (W) | 4568 | 6496 | 8420 | 10270 | 14820 | 16000 | 17510 |
| Rated input (W) | 1120 | 1693 | 2160 | 2780 | 3400 | 3820 | 4310 | |
| COP | 4.09 | 3.84 | 3.89 | 3.69 | 4.36 | 4.19 | 4.06 | |
| Heating A7W55 | Capacity (W) | 4669 | 6293 | 7800 | 9500 | 14680 | 15800 | 17230 |
| Rated input (W) | 1440 | 2010 | 2360 | 2920 | 3420 | 3860 | 4380 | |
| COP | 3.23 | 3.13 | 3.30 | 3.25 | 4.29 | 4.10 | 3.93 |
Heat Pump Sound Pressure Levels 1m [dB(A)]
| Mode | ACHP-H04/4R2HA-M | ACHP-H06/4R2HA-M | ACHP-H08/4R2HA-M | ACHP-H10/4R2HA-M | ACHP-H12/4R2HA-M | ACHP-H14/4R2HA-M | ACHP-H16/4R2HA-M |
|---|---|---|---|---|---|---|---|
| Heating A7W35 | 48 | 49 | 48 | 49 | 46 | 47 | 47 |
| Heating Max | 50 | 51 | 50 | 51 | 48 | 49 | 50 |
| Heating Silence I | 45 | 46 | 45 | 46 | 44 | 45 | 45 |
| Heating Silence II | 42 | 43 | 42 | 43 | 43 | 43 | 43 |
Product Downloads
Download all available details related to this specific product
FAQ
How is AUX UK magnetic filter different than other brands?
We have a specially designed heat pump filter built with a strong magnet and double mesh strainer as the Y shape filters supplied with most ASHP units are getting blocked too easily and cause circulation problems. This is similar to Caleffi's expensive filter with a brush mechanism inside, which allows service engineers and homeowners to easily flush and clean the filter without isolating and opening / removing.
What comes in the Box?
- Our heat pumps have built in 3kw backup heater, circulation pump, expansion vessel, safety valve controls and cables.
- Wired controller is included in the package, they also act as smart thermostat.
- There are 2x10m cables, one for cylinder sensor and one for wired controller
- There is expansion vessel and circulation pump inside each pump.
- You need to buy our magnetic filter, 3 way diverter valve, feet, isolation valve, buffer tank and pipe and fittings additionally.
Do you have a heat pump suitable for coastal houses?
Our heat pumps have gold plated fins so you can use it in the costal areas.
How much is the safety area?
Safety Area is 300mm
