SKU: A1513
£574.80 Incl. VAT
Available on working days between 9:00 am to 6:00 pm
Available on working days between 8:00 am to 5:00 pm
| Model | Unit | AUX-09CM | AUX-12CM | AUX-18CM | AUX-24CM | |
|---|---|---|---|---|---|---|
| Cooling capacity | [kW] | 2,70 | 3,50 | 5,35 | 7,20 | |
| Heating capacity | [kW] | 3,30 | 4,20 | 5,65 | 6,80 | |
| Power supply | [V~,Hz,Ph] | 220-240, 50, 1 | 220-240, 50, 1 | 220-240, 50, 1 | 220-240, 50, 1 | |
| Operating current | Cooling | [A] | 3,30 | 4,20 | 6,40 | 9,50 |
| Heating | [A] | 3,90 | 4,80 | 6,10 | 8,00 | |
| Energy consumption | Cooling | [W] | 720 | 870 | 1430 | 2100 |
| Heating | [W] | 800 | 1060 | 1330 | 1750 | |
| Maximum current draw | [A] | 9,0 | 9,0 | 12,0 | 16,0 | |
| Maximum energy consumption | [W] | 1600 | 1500 | 2400 | 3200 | |
| SEER / SCOP | – | 8,50 / 4,60 | 8,50 / 4,60 | 8,80 / 4,60 | 8,70 / 4,60 | |
| Energy efficiency class | Cooling | – | A+++ | A+++ | A+++ | A+++ |
| Heating | – | A++ | A++ | A++ | A++ | |
| Indoor unit | AUX-09CM/I | AUX-12CM/I | AUC-18CM/I | AUX-24CM/I | ||
| Air flow | [m3/h] | 600 | 650 | 1000 | 1300 | |
| Sound power level | [dB(A)] | 54 | 56 | 56 | 62 | |
| Sound pressure level | [dB(A)] | 23 – 41 | 20 – 42 | 24 – 46 | 27 – 50 | |
| Indoor unit dimensions | [mm] | 768 x 299 x 201 | 827 x 299 x 201 | 11450 x 332 x 230 | 1132 x 333 x 230 | |
| Indoor unit weight | [kg] | 8,0 | 8,5 | 13,5 | 14,0 | |
| Outdoor unit | AUX-09CM/O | AUX-12CM/O | AUX-18CM/O | AUX-24CM/O | ||
| Refrigerant | Type | – | R32 | R32 | R32 | R32 |
| Factory charge (up to 5m) | [g] | 550 | 600 | 1030 | 1200 | |
| Additional charge | [g/m] | 20 | 20 | 20 | 30 | |
| Sound power level | [dB(A)] | 61 | 62 | 63 | 65 | |
| Sound pressure level | [dB(A)] | 51 | 51 | 53 | 56 | |
| Outdoor unit dimensions | [mm] | 705 x 279 x 530 | 705 x 279 x 530 | 785 x 300 x 555 | 900 x 350 x 700 | |
| Outdoor unit weight | [kg] | 23,5 | 23,5 | 28,5 | 41,0 | |
| Outdoor unit oper. (outside temp.) | Cooling | [°C] | -15 | -15 | -15 | -15 |
| Heating | [°C] | -30 | -30 | -30 | -30 | |
Download all available details related to this specific product
